11.1 Prior to each time the application is used
 Check the connecting cable for signs of damage or ageing. Replace the cable if it is
cracked, split or otherwise damaged.
 Check the condition of the cutting cylinder, and ensure that all threaded connections are
securely tightened.
 If the tines are blunt, take it to a specialist workshop for repair if necessary.
11.2 Once per season
 Lubricate the tines and shaft.
 At the end of the season, have the application checked and serviced in a specialist
workshop.
Warning! Always clean the application after use. Failure to carry out proper
cleaning can result in damage to the application or cause it to malfunction.
Whenever possible, clean the application straight after you have finished working on the lawn.
 Clean the underside of the housing around the tines and the protective shield and fender
with a scrubbing brush, and brush or soft cloth dampened with a mild soap and water
mixture. Never splash with water!
 To remove soil and debris from the tines and transmission, use a stiff brush or a
dampened cloth.
 Clean the ventilator, and remove any remaining grass or dirt.
 Once cleaned, wipe the tine and shaft dry and apply a light coat of oil.
11.3 Tines Removal and Installation (Fig. 5)
Worn tines invites poor performance and overload of motor.
Check before each use the tines situation. Sharpen or replace the tines with new one when
necessary. It is recommended to let this be done by a specialist.
Caution! Disconnect the mains and wear protective gloves.
To remove the complete tines from the shaft:
 To remove the complete tine assemblies from the shaft, remove the M8x40 hex head bolt
from the shaft.
 Take off the outer tine set from shaft.
 Reverse above steps to install tines.
11.4 Change tines from bracket
When one or two pieces of tine broken, it is necessary to change the damaged tine instead of
complete tine set.
 Loosen the screws from one side while hold the lock nuts from other side.
 Take off the damaged tine and replace with the new one.
11.5 Checking transmission lubricant (Fig. 6)
Drain screw plug is located on the right side of transmission housing.
 Lay the tiller on its left side and clean the transmission to prevent dirt and debris before
remove the drain screw.
 Using a hex key 8 mm to unscrew the plug and empty the oil from the transmission.
 Fill up by using a grease gun with a high-quality, automotive-grade grease until it begins to
seep out around the edge of the hole of the nozzle.
 If necessary, disassemble tines.
 Reinstall the drain screw plug.
12 STORAGE
The tiller should be stored in a dry and clean room and out of reach of children.
During extended periods of storage, during the winter for example, ensure that the application
is protected against corrosion and frost.
