Powerplus POWXG9008 - TECHNICAL DATA; NOISE; CLEANING AND MAINTENANCE; After each use

POWXG9008 EN
Copyright © 2015 VARO NV P a g e | 10 www.varo.com
12 TECHNICAL DATA
MOTOR
Engine power
3.5 kW
Rotation speed
3000 min-1
Fuel tank
3.6 l
Fuel
Unleaded gasoline / E10
Engine Type
OHV 4-stroke
Starting System
Recoil
Displacement
180 cc
Oil type
15W-30(SAE30)
WATER CONNECTION
Max. feed temperature
50 °C
Min. feed volume
626 l/h
Min. feed pressure
0.2 Mpa (2bar)
Max. feed pressure
1 MPa (10 bar)
Inlet hose length
≥ 3m
Inlet hose diameter (inner diameter)
≥ 12mm
PUMP
Working pressure
186 bar
Flow rate
522 l/h
Oil quantity - pump
65 ml
Detergent suck
4,2 l/h
Max. recoil force of hand spray gun
28 N
On board detergent tank
1.13 l
Weight without accessories
28 kg
13 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
90 dB(A)
Acoustic power level LwA
105 dB(A)
ATTENTION! Wear hearing protection when sound pressure is
over 85 dB(A).
aw (Vibration)
2.1 m/s²
K = 1.5 m/s²
14 CLEANING AND MAINTENANCE
14.1 After each use
 Shut off engine and turn off water supply. Release water pressure by pointing spray gun
in a safe direction and squeezing the trigger.
 Disconnect high pressure hose, spray gun and nozzle. Drain water from items and use a
rag to wipe down the outside of the hose and spray gun.
 Empty the water from the pump by pulling the recoil starter 6 times.
 Store unit in a clean and dry area.
