POWXG9008 EN
Copyright © 2015 VARO NV P a g e | 7 www.varo.com
9.4 Assembly of the siphon tube (Fig. 4)
Attach the other side of the onboard tank siphon tube to the left mouth of the selector knob
Attach the other side of the pump siphon tube tot the bottom mouth of the selector knob
9.5 Assembly of the spray gun (Fig. 5-6)
Fit the lance to the gun (4). Grip the end of the gun and screw the lance onto the gun ensuring
it is tight. Do not over tighten as this could damage both the connectors
Connect the high pressure hose connector to the connector on the underside of the gun
assembly ensuring that it is tight. Do not over tighten as this could damage both the
connectors.
10 BEFORE OPERATION
To prepare your pressure washer for operation, you will need to perform these tasks:
 Add oil to engine crankcase.
 Add fuel to fuel tank.
 Connect high pressure hose to spray gun and pump.
 Connect water supply to pump.
 Attach nozzle extension to spray gun.
Note: the engine and pump on your new pressure washer will often have an improved
performance after a break of several hours.
10.1 Add oil to the engine crankcase (Fig. 7)
Do not attempt to start the pressure washer without filling the engine crank case (25 & 27) with
the proper amount and type of oil (15W-30 (SAE30)). In delivery status the pressure washer
has no oil inside the engine crank case. Operating the unit without oil will cause engine
damage. Place the machine on a level surface and remove the oil filler cap.
Add engine oil to at least half of the dipstick.
10.2 Add fuel to fuel tank (Fig. 8)
The pressure washer is powered by a four-stroke engine (14), which uses unleaded petrol fuel.
Use a suitable funnel to fill in the fuel to the engines fuel tank (11). Do not spill any fuel or
overfill the tank. The fuel tank should not be filled above the top of the fuel filter.
10.3 Connecting the water hose to the High pressure washer (Fig. 9)
 Run water through the hose for a few seconds to flush any debris from the hose.
 Inspect inlet screen and remove any debris.
 Connect hose to water inlet and tighten by hand.
 Turn on water.
Do not run the pump without connecting to the water supply and turning
the water on. Such failure can damage the pressure washer.
10.4 Connect the high-pressure hose to the delivery pipe outlet (Fig .10)
 Attach the end of the high pressure hose to the high pressure outlet.
 Turn on the water supply and squeeze the gun trigger until the water flows in a steady
stream through the lance. Do not use water which exceeds 40 °C.
