To ensure appliance safety, use only original spare parts from the manufacturer or approved
by the manufacturer.
WARNING: High Pressure hoses, fittings, and couplings are important for the safety of the
appliance. Use only fittings and couplings recommended by the manufacturer.
Do not use the appliance, if a supply cord or important parts are damaged, e.g. safety devices,
high pressure hoses, trigger gun.
WARNING: Incorrect fuels shall not be used as they may prove hazardous.
WARNING: Do not use combustion engine powered appliances indoors unless adequate
ventilation is assessed by national labour authorities.
WARNING: Ensure that any exhaust emissions are not in the vicinity of air intakes.
7 SAFETY WARNINGS GASOLINE
WARNING: Use extra care in handling fuels. They are flammable and the vapours are
explosive. The following points must be observed.
Use only an approved container.
Never remove the fuel cap or add fuel with the power source running. Allow engine
exhaust components to cool before refuelling.
Do not smoke.
Never refuel the machine indoors.
Never store the machine or fuel containers inside, where is an open flame, such as a
water heater.
If fuel is spilled, do not attempt to start the power source, but move the machine away
from the area of spillage before starting.
Always replace and securely tighten the fuel cap after refuelling.
If the tank is drained, this should be done outdoors.
8 SAFETY FEATURES
8.1 Thermal relief valve
A thermal relief valve is provided to protect the pump from overloading if the spray gun is
closed for an extended length of time or the nozzle becomes plugged. However, it is intended
to be used as a backup system and avoid the overheating of the pump.
Switch the pressure washer "OFF", if it will not be used for longer than five minutes. This
reduces wear, prevents fuel consumption and extends the live of the pump by avoiding heat.
8.2 Safety lock off latch
To prevent accidental discharge of high pressure water, the safety latch on the trigger should
be engaged whenever the pressure washer is not in use (refer to operating instruction).
9 ASSEMBLY INSTRUCTIONS
Remove all packaging materials from the unit. Check the main unit, its components and all
accessories for loss and transport damages.
9.1 Assembly of the foot (Fig. 1)
Parts needed: 1 foot and 1 M8 lock nuts
9.2 Assembly of the handle (Fig. 2)
Install upper frame onto the lower frame and pressing down firmly until the two pins snap in
pace.
9.3 Assembly of the upper and lower lance hook (Fig. 3)
Attach the upper lance hook: install two plastic rivets, you may need to tap with a hammer to
seat the lock pin.
Attach the lower lance hook: install the M6 screw & lock nut, wrench tighten unitl the nut is
snug.
