Part Stock# Description Qty
Part Stock# Description Qty
1 303020248 Hex Flange Bolt M6×12 4
25 203010907 Right Bracket 1
2 203050513 Big Bottom Plate 1
26 303160838 Auger Motor Casing 45# 1
3 303240647 Controller 147×150×17 1
27 303160658 DB7004 Small Pulley Wheel 1
4 303043068 Flat Washer 4 2
28 303043069 Flat Washer 6 1
5 303010026 Screw 4.2×12 24
29 303041009 Spring Washer 6 1
6 303130122 DB2401 Battery Pack Spring 2
30 303020637 Hex Bolt M6×20 1
7 203010859 Charger Cartridge Holder 1
31 203050636 Belt Cover 1
8 203050554 Battery Fixed Seat 1
32 203050557 Drive Motor Fixed Seat 1
9 202470007 DB2208 Charger 1
33 303100011 6900Z Bearing 1
10 202460006 DB2108 80V6Ah Battery 1
34 303160839 Small Drive Gear 45# 1
11 203010783 Switch Cover 1
35 303020087 Bolt M6×25 1
12 203021264 Safety Key 1
36 303030032 Lock Nut M6 2
13 301100055
Child lock contact switch：
MSG-1130 30A 84Vdc
1
37 301030089 80VDC Drive Brushless Motor 1
14 303130360 Battery Snap Spring 0.6 1
38 303181293 Frame Welded 1
15 303123035 Cylindrical Pinφ6x50mm 1
39 303042095 Flat Washer 6 4
16 203050635 Battery Self - lock button 1
40 303060143 Frame Seals 1
17 203010903 Lower Batter Cover 1
41 303122002 Dowel Pins 2
18 203020047 Cable Clamp 4
42 302090365 13" Tire 2
19 203010906 Left Bracket 1
43 203050140 Wheel Spacer 2
20 203010904 Middel Batter Cover 1
44 303060030 Six-party Bushing 2
21 203010905 Upper Battery Cover 1
45 303170016A Wheel Shaft 1
22 303010185 Screw 6.3×30 16
46 303020442 Hex Bolt M6×35 1
23 303181251 Auger Motor Hoop 1
47 303160837 Big Gear 1
24 301030088 80VDC Auger Brushless Motor 1
48 303050028 Shaft Ring 19 1
