Powersmart DB9422SR - Page 24

24
Item Stock# Description Qty Item Stock# Description Qty
E01-1 11310-Z970110-00A0
CRANKCASE
SUBASSEMBLY.
1 E08-1 80001-Z870110-Q200 HOUSING, ENGINE
1
E01-2 90103-0410-51 BOLT 1 E08-2 90107-0516-01 SCREW
2
E01-3 12045-Z240110-00A0 Reed valve limit plate 1 E08-3 28110-Z870130-0000 SHROUD
1
E01-4 11321-Z180110-00A0 PIECE, BREATH 1 E08-4 28001-Z870110-0000 STUD
1
E01-5 11331-Z180110-00A0
STRAINER, BREATH
GROOVE
1 E08-5 28001-Z870210-0000 STUD
2
E01-6 11332-Z180110-00A0
GASKET, BREATH
GROOVE
1 E08-9 90255-0520-51 BOLT
1
E01-7 11333-Z180110-00A0
PLATE, BREATH
GROOVE COVER
1 E09-2 17001-Z030120-0000 GASKET, AIR CLEANER 1
E01-8 90007-0612-A1 BOLT 2 E09-3 16100-Z970110-00A9 CARBURETOR ASSY. 1
E01-9 90682-Z240110-0000 SEAL, OIL 1 E09-4 90204-Z250310-00A0 BOLT
2
E01-10 19340-Z870120-0000 SHIELD,LOWER 1 E09-5 16001-Z010110-0000 GASKET, CARBURETOR 3
E01-11 90007-0612-A1 BOLT 1 E09-6 16003-Z250210-0000 PLATE, CARBURETOR INSULATOR 2
E02-1 11411-Z870130-00A0 COVER, CRANKCASE
1
E09-7 16004-Z870110-0000 GASKET, INSULATOR PLATE 1
E02-2 90007-0620-A1 BOLT
6
E09-8 16004-Z870210-0000 GASKET, INSULATOR PLATE 1
E02-3 90007-0655-A1 BOLT
2
E09-9 16210-Z250120-00A0 VALVE, STARTING RICHED
1
E02-4 90502-0818-00 PIN
2
E09-10 90685-0700-01 CLAMP
2
E02-5 15010-Z870210-Q2A0
DIPSTICK
SUBASSEMBLY, OIL 1
E09-11 16211-Z870110-0000 TUBE, STARTING RICHED VALVE
1
E02-6 16400-Z870120-0000
GEAR ASSY,
GOVERNOR
1
E10-1 13510-Z870110-0000 FLYWHEEL SUBASSEMBLY 1
E02-7 16061-Z870120-0000 ARM, GOVERNOR
1
E10-2 13501-Z010110-0000 NUT, FLYWHEEL 1
E02-8 90412-Z870210-0000 Flat washer
1
E10-3 30400-Z340410-02A0 COIL, IGNITION 1
E02-9 90682-Z030210-0000 SEAL, OIL
1
E10-4 90007-0612-A1 BOLT 2
E02-10 90007-0612-A1 BOLT
1
E10-5 45200-Z970110-00A0 BRAKE ASSY. 1
E02-11 90501-Z010110-0000 PIN
1
E10-6 90007-0625-A1 BOLT 1
E02-12 90682-U090110-0000 SEAL, OIL
1
E11-1 16062-Z870110-0000 ROD, GOVERNEOR
1
E02-13 16013-Z030120-0000
PLATE, GOVERNOR
SPINDLE
COMPRESSION
1
E11-2 16012-Z870110-0000
SPRING, THROTTLE VALVE
RETURNING
1
E03-1 97002-Z240110-0000 Valve control assembly
2
E11-3 16070-Z870110-0000
SUPPORT SUBASSEMBLY,
GOVERNOR
1
E03-2 14311-Z870110-0000 ROCKER, VALVE
1
E11-4 90305-0600-31 NUT
1
E03-3 14313-Z240110-0000 BOLT, ROCKER SHAFT
2
E11-5 16072-Z010110-0000 BOLT, GOVERNOR SUPPORT
1
E03-4 14091-Z870110-00A0
PLATE SUBASSEMBLY,
LIFTER STOPPER
1
E11-6 16063-Z870110-0000 SPRING, GOVERNOR
1
E03-5 12101-Z810210-0000 GUIDE, SEAL
1
E11-7 90007-0612-A1 BOLT
1
E03-6 12112-Z350110-00A0 SEAT, VALVE SPRING
2
E11-8 16561-Z240110-00A0
PLATE SUBASSEMBLY, THROTTLE
CONTROL BOTTOM
1
E03-7 12103-Z010110-0000 SPRING, VALVE
2
E11-9 90684-Z250110-00A0 CLIP
1
E03-8 12110-Z870110-00A0 VALVES SET
1
E11-10 90007-0620-A1 BOLT
1
E03-9 14071-Z340110-0000 LIFTER, VALVE
2
F01-1 17004-Z870110-0000 TUBE, BREATHER
1
E03-10 14081-Z800110-0000 TAPPET, VALVE
2
F01-2 17100-Z870110-0000 CLEANER, AIR
1
E03-11 14200-Z870110-00A0 CAMSHAFT ASSY.
1
F01-3 90305-0600-31 NUT
2
E03-12 90007-0612-A1 BOLT
5
F02-1 18130-Z870110-00A0 COVER, MUFFLER OUTER
1
E03-13 12411-Z970110-00A0
COVER, CYLINDER
HEAD
1
F02-2 18100-Z870110-00A0 MUFFLER ASSY.
1
E03-15 30010-Z180110-00A0 PLUG, SPARK
1
F02-3 18001-Z870110-00A0 GASKET, EXHAUST OUTLET
1
E03-16 14311-Z870210-0000 ROCKER, VALVE
1
F02-4 90310-0600-31 NUT
2
E04-1 13200-Z970110-00A0 RING ASSY, PISTON 1 F02-5 90207-Z970110-0000 BOLT
2
E04-2 13111-Z970110-00A0 PISTON 1 F03-1 16730-Z620210-LKD0 COVER, FUEL TANK
1
E04-3 13122-Z350110-00A0 CLIP, PISTON PIN 2 F03-2 16620-Z870110-Q299 TANK, FUEL
1
E04-4 13121-Z970110-00A0 PIN, PISTON 1 F03-3 90007-0625-A1 BOLT
1
E04-5 13010-Z870110-00A0 ROD, CONNECTING 1 F03-4 16652-Z030110-00A0
STRAINER，FUEL
1
E04-6 13300-Z870810-0000 CRANKSHAFT ASSY. 1 F03-5 90685-1000-01 CLAMP
1
E04-7 90408-Z030210-0000
WASHER， FLAT
1 F03-6 90686-Z870110-0000 TUBE, FUEL
1
E04-8 90408-Z240210-00A0
WASHER， FLAT
2 F03-7 90685-0700-01 CLAMP
1
E07-1
90305-0600-31
NUT
3
F03-8 16744-Z620120-0000
CHAIN PROOF OFF， FUEL TANK
COVER
1
E07-2
28200-Z180130-00D0
STARTER ASSY,
RECOIL
1
