Powersmart MB7109A - Page 18

1
CHUTE ASSEMBLY
Item
Stock#
Description
Qty
Item
Stock#
Description
Qty
86
202120186
Chute
1
87
303020655
Bolt
1
87
303020655
Bolt
2
95
202180003
Steering gear
1
50
303041022
spring washer
2
89
303030087
Nut
2
43
303042023
Flat washer
2
96
303020084
Bolt
2
88 303081362
Chute Support Tube
Welding
1 97 202180004 Steering pinion 1
89
303030087
Nut
2
98
203010817
Steering gear cover
1
90
303020507
Bolt
2
99
303010026
Screw
2
91
303181363
Support Tube Welded
1
100
303160845
Dowel Pin
1
21
303030077
Flange Lock Nut M8
1
101
303160905
Z-long rocker
1
92
303130369
Compression spring
1
102
203021460
Rocker lever
1
93
303071056A
Locating plate
1
62
303042004
Flat washer
2
94 203020380 Tooth pad 2 103 303050029 Shaft Ring 1
