ASSEMBLY INSTRUCTIONS
WARNING:
Do not use this product if any parts on the packing list are already assembled to your product
when you unpack it. Parts on this list are not assembled to the product by the manufacturer
and require customer installation. Use of a product that may have been improperly assembled could result
in serious personal injury.
WARNING:
If any parts are damaged or missing do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could result in serious personal injury.
WARNING:
Do not attempt to modify this product or create accessories not recommended for use with
this product. Any such alteration or modification is misuse and could result in a hazardous
condition leading to possible serious personal injury.
WARNING:
Do not connect to power supply until assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
WARNING:
Before assembly, make sure that the tool is switched off and the battery has been removed.
CONNECTING THE UPPER SHAFT AND THE TELESCOPIC SHAFT
Align the arrow on the lock sleeve with the gap on the upper shaft, insert the telescopic shaft (K) into
the upper shaft (M) (See fig.1).
Then use the hex key to tighten the bolt (See fig.2).
Fig.1
Fig.2
K
M
