Powersmart PS76417 - Page 27

Item Stock# Description Qty Item Stock# Description Qty
1 202470005 Charger assembly 1 44 203050593 Side discharge frame 1
2 203010895
Battery pack outer upper
cover
1 45 203050594 Side discharge coverplate 1
3 302060036 Plastic plug 2 46 303160833 Side discharge holder 1
4 203010896 Battery pack cover holder 1 47 303130335A
Side discharge torsional
spring
1
5 303010237 Screw ST4.2X10 9 48 303160410A Torsional spring pin 1
6 303010270 Screw ST4.2X14 9 49 203050595 8" right wheel 1
7 202460007 battery pack assembly 1 50 303181203 Rear axle welding 1
8 202460009 40V battery pack 1 51 303071467 Spring assembly 1
9 203021266 Charger cartridge holder 1 52 203050596 8" left wheel 1
10 303010281 Screw ST4.2X18 18 53 302080074B Plastic barrier 1
11 303130355 The battery pack spring 1 54 203050597A Wind deflector 1
12 203021389 Secure Key 1 55 303030140 Square nut 2
13 203010897 Switch upper cover 1 56 203050598A Back seat 1
14 301100055 Switch 1 57 303130364
Back cover left torsion
spring
1
15 303042019 Flat washer
2
58 203050599A Rear cover 1
16 203021390 Battery pack cover 1 59 303130337
Back cover right torsion
spring
1
17 303100086 Battery pack cover shaft 2 60 203050600 Rear blanking cap 1
18 203020047 The cable clamp 2 61 302120068 Collection bag 1
19 301011024 40V controller assembly 1 62 303081195 Grass collecting support 1
20 303043078 Flat washer 4 63 303121005 Cotter 2
21 303071474 Controller pressure plate 1 64 303160807 Axis pin 2
22 303010377 Screw 2 65 303020558 Flange bolts 2
23 301030079 Motor 1 66 303081196 Lower left tube 1
24 203021391 Motor base 1 67 303081197 Lower right tube 1
25 303010357 Hex lock nut M8 3 68 303020140 T-bolt M8*50 2
26 203050590 Front cover 1 69 302060037 End plug 2
27 303010332 Screw ST6.3*20 15 70 303030026 Thickened plain nut M8 2
28 303010359 Hex lock nut 4 71 203021381 Knob 2
29 203050591 7" right wheel 1 72 303081198 Upper tube 1
30 303181207 Front wheel shaft welding 1 73 203050601 Clip 2
31 303071420 Wheel clamp 4 74 306040026 Connecting cable 1
32 303010355 Screw ST6.3×20 8 75 306040027 Operation plate 1
33 203050592 7" left wheel 1 76 301100046 Switch 1
34 303071466 Spring assembly 1 77 302070001 Seal ring 4
35 303030032 Hex lock nut 4 78 203050602 Lower switch box 1
36 303020644 Hexagon flange bolt 4 79 303130124 Spring 1
37 303020635 Bolt M6*12 4 80 203010655 Swith pushing pod 1
38 203021355 Blade bolt Nylon cover 1 81 203021102A Switch button 1
39 203021393 Motor fan 1 82 303130013 Spring 1
40 303240634 17" blade 1 83 203021395 Right switch trigger 2
41 303020649 Hexagon flange bolt 3 84 203050603 Upper switch box 1
42 303181285 Deck 1 85 303130125
Anti self locking button
spring
1
43 303020648 Bolt M6×10mm 2 86 203010898 Anti self locking button 1
