16
TO INSTALL BATTERY PACK (See Figure 6)
• Lift and hold up the battery door.
• Place the battery pack on the mower. Align guided ribs on battery pack with grooves in the
product’s battery port.
• Make sure the latch on bottom of the battery pack snaps in place and that battery pack is fully
seated and secure in the product before beginning operation.
• Insert the safety key.
• If the machine is not going to be used immediately, do not insert the safety key.
• Close the door.
Figure 6
TO REMOVE BATTERY PACK (See Figure 6)
• Release the mowing trigger as shown in the machine indicator diagram above to stop the product.
• Remove the safety key.
• Press and hold the battery latch button at the bottom of the battery pack.
• Remove battery pack from the product.
Battery pack
Battery door
Safety
