Powersmart PS76821 - Page 27

Item Stock# Description Qty Item Stock# Description Qty
1 202470009 Charger assembly 1 26 202040068 1200W motor (80V) 1
2 203010895
Battery pack outer
upper cover
1 27 203021391 Motor base 1
3 302060036 Check valve 2 28 303020635 Bolt M6*12 4
4 301120010 Lamp 1 29 303020649 Bolt M8*20 3
5 203010896
Battery pack outer
middle cover
1 30 303010332 Screw ST6.3*20 15
6 303010237 Screw 6 31 203050623C Front cover 1
7 303130355 The battery pack spring 2 32 303181288 21" connecting rod 1
8 203010871 Cartridge holder 1 33 303030032 Hex lock nut M6 4
9 203010858
Charger insert bracket
press
plate
1 34 203050665
Right front fwheel
cover
1
10 303010358 Screw 9 35 303030077 Hex lock nut M8 4
11 202460014 Battery pack 80V/6Ah 1 36 203021417
Front wheel shaft
sleeve
4
12 203021389 Secure Key 1 37 203050625 Rear wheel 2
13 203010897 Switch upper cover 1 38 303181190 21" front axle welding 1
14 301100055 Switch 1 39 303071420 Wheel clamp 4
15 303043077 Flat washer 1 40 303010216 Screw ST6.3X20 14
16 203021400 Self-locking push switch 1 41 203050667
8" front left wheel
cover
1
17 303160814
Battery pack self -
locking switch shaft
1 42 203021392
Blade bolt Nylon
cover
1
18 303130356
Self-locking switch
spring
1 43 303240638 21" blade 1
19 203021390 Battery pack cover 1 44 203021393 Motor fan 1
20 303100086 Battery pack cover shaft 2 45 203050626A Wind shield 1
21 203020047 The cable clamp 2 46 303071468C Deck 1
22 303010028 Screw 32 47 203050593 Side discharge frame 1
23 301011020
Controller assembly
(single tool)
1 48 303160410A Torsional spring pin 1
24 303042104 Flat washer 2 49 303020468 Outer hexagon bolt 2
25 303010357 Hex lock nut M8 5 50 303160833 Side discharge holder 1
