25
Item Stock # Description Qty Item Stock # Description Qty
E01-1 11310-Z3C0110-00A0
CRANKCASE
SUBASSEMBLY.
1 E04-3 90408-Z030210-0000 WASHER， FLAT 1
E01-2 90682-Z240110-0000 SEAL, OIL 1 E04-4 14200-Z2P0110-00A0 CAMSHAFT ASSY. 1
E01-3 90682-Z030210-0000 SEAL, OIL 1 E04-5 13122-Z240110-00A0 CLIP, PISTON PIN 2
E01-4 90103-0410-51 SCREW 1 E04-6 13121-Z240110-00A0 PIN, PISTON 1
E01-5 11321-Z2P0110-0000 PIECE, BREATH 1 E04-7 13010-Z2P0110-00A0 ROD, CONNECTING 1
E01-6 11337-Z2P0110-0000 LIMIT BOARD 1 E04-8 13111-Z3C0110-00A0 PISTON 1
E01-7 90007-0512-A1 BOLT 1 E04-9 13200-Z870110-00A0 RING ASSY, PISTON 1
E01-8 11333-Z2P0110-0000
PLATE, BREATH
GROOVE COVER
1 E05-1 90107-0516-01 SCREW 3
E01-9 16061-Z2P0110-00A0 ARM, GOVERNOR 1 E05-2 80001-Z2P0210-RC00 HOUSING, ENGINE 1
E01-10 90501-Z010110-0000 PIN 1 E05-3 28200-Z2P0310-Q200
STARTER ASSY,
RECOIL
1
E01-11 90412-Z870210-0000 WASHER， FLAT 1 E05-4 90007-0516-A1 BOLT 4
E01-12 16062-Z2P0110-0000 ROD, GOVERNEOR 1 E06-1 90204-Z010210-0100 BOLT 1
E01-13 16072-Z010110-0000
BOLT, GOVERNOR
SUPPORT
1 E06-2 17002-Z2P0110-00A0 GASKET, INLET 1
E01-14 90305-0600-31 NUT 1 E06-3 16003-Z2P0110-00A0
PLATE,
CARBURETOR
INSULATOR
1
E01-15 16070-Z2P0110-0000
SUPPORT
SUBASSEMBLY,
GOVERNOR
1 E06-4 16004-Z2P0110-00A0
GASKET, INSULATOR
PLATE
1
E01-16 16063-Z2P0110-0000 SPRING, GOVERNOR 1 E06-5 16100-Z3C0210-00A0 CARBURETOR ASSY. 1
E01-17 19308-Z2P0110-0000
SHIELD, CRANKCASE
SIDE
1 E06-6 90685-1000-01 CLAMP 1
E01-18 90007-0512-A1 BOLT 1 E06-7 90686-Z2P0110-0000 TUBE, FUEL 1
E01-19 11340-Z2P0110-0000 Return oil block assembly 1 E06-8 90685-0700-01 CLAMP 2
E01-20 16561-Z2P0110-0000
PLATE SUBASSEMBLY,
THROTTLE CONTROL
BOTTOM
1 E06-9 16211-Z2P0110-0000
TUBE, STARTING
RICHED VALVE
1
E01-21 90007-0512-A1 BOLT 1 E06-10 16212-Z2P0110-0000
SEAT, STARTING
RICHED VALVE
1
E01-22 15010-Z2P0310-Q200 DIPSTICK, OIL 1 E06-11 16213-Z2P0110-0000
VALVE BODY,
STARTING RICHED
1
E02-1 11411-Z2P0110-00A0 COVER, CRANKCASE 1 E10-1 13501-Z010110-00A0 NUT, FLYWHEEL 1
E02-2 90682-Z030320-0000 SEAL, OIL 1 E10-2 19352-Z2P0110-00A0 IMPELLER 1
E02-3 90001-0630-01 BOLT 7 E10-3 28020-Z2P0110-0000 SEAT, STARTER CUP 1
E02-4 16400-Z2P0111-00A0
GEAR ASSY,
GOVERNOR
1 E10-4 13510-Z2P0110-00A0
FLYWHEEL
SUBASSEMBLY
1
E02-5 16013-Z030120-0000
PLATE, GOVERNOR
SPINDLE
COMPRESSION
1 E10-5 30029-Z2P0110-0000 LUG， SHROUD 1
E02-6 90001-0616-01 BOLT 1 E10-6 90007-0516-A1 BOLT 1
E02-7 90502-0812-00 PIN 2 E10-7 45200-Z2P0110-JS00 BRAKE ASSY. 1
E03-1 14081-Z2P0110-00A0 TAPPET, VALVE 2 E10-8 90007-0520-A1 BOLT 3
E03-2 14071-Z2P0110-00A0 LIFTER, VALVE 2 E10-9 30400-Z2P0110-0000 COIL, IGNITION 1
E03-3 12131-Z3C0110-00A0
GASKET, CYLINDER
HEAD
1 F01-1 17001-Z2P0110-00A0
GASKET, AIR
CLEANER
1
E03-4 12140-Z3C0110-00A0
HEAD SUBASSEMBLY,
CYLINDER
1 F01-2 17100-Z2P0110-0000 CLEANER, AIR 1
E03-5 90001-0850-01 BOLT 4 F01-3 90305-0600-31 NUT 2
E03-6 30010-Z120110-00A0 PLUG, SPARK 1 F01-4 17004-Z2P0110-0000 TUBE, BREATHER 1
E03-7 12101-Z810210-00A0 GUIDE, SEAL 1 F02-1 90107-0413-03 BOLT 3
E03-8 12110-Z3C0110-00A0 VALVES SET 2 F02-2 18130-Z2P0210-0000
COVER, MUFFLER
OUTER
1
E03-9 12103-Z030110-0000 SPRING, VALVE 2 F02-3 90001-0616-01 BOLT 2
E03-10 12112-Z010110-00A0 SEAT, VALVE SPRING 2 F02-4 18100-Z2P0210-0000 MUFFLER ASSY. 1
E03-11 14310-Z2P0110-00A0
ROCKER
SUBASSEMBLY,
VALVE
2 F02-5 18020-Z2P0110-00A0
PLATE, MUFFLER
INSULATOR
1
E03-12 14330-Z2P0110-00A0
SHAFT, VALVE
ROCKER
1 F03-1 16600-Z2P0110-Q2A9 TANK ASSY, FUEL 1
E03-13 12411-Z2P0110-0000
COVER, CYLINDER
HEAD
1 F03-2 16744-Z620120-0000 TANK CAP CHAIN 1
E03-14 90007-0512-A1 BOLT 4 F03-3 16730-Z620210-LKD0 COVER, FUEL TANK 1
E04-1 13300-Z3C1110 CRANKSHAFT ASSY. 1 F03-4 16652-Z030110-00A0 STRAINER，FUEL 1
E04-2 14014-Z2P0210-00A0 GEAR, TIMING DRIVE 1 F03-5 90685-1000-01 CLAMP 1
