7. Protection
 Battery Over Voltage Protection
When the battery voltage reaches to the set point of Over Voltage
Disconnect Voltage(OVD), the controller will stop charging the battery to
protect the battery from being over charged to break down.
 Battery Over Discharge Protection
When the battery voltage reaches to the set point of Low Voltage
Disconnect Voltage(LVD), the controller will stop discharging the battery to
protect the battery from being over discharged.
 Load Overload Protection
Load will be switched off when 1.25 times rated current overload happens.
User has to reduce load appliance, then press the button or repower the
controller.
 Load Short Circuit Protection
Load will be switched off when load short circuit (≥3 times rated current)
happens. User has to clear short circuit, then press the button or repower
the controller.
 High Voltage Transients Protection
The controller is protected against small high voltage transients. In lightning
prone areas, additional external suppression is recommended.
8. Troubleshooting
Faults
Possible reasons
Troubleshooting
LED Charging
indicator turn off
during daytime
when sunshine falls
on PV modules
properly
PV array
disconnection
Confirm that PV and battery
wire connections are correct
and tight
No LED indicator
Battery voltage
maybe less than 8V
Measure battery voltage with
the multi-meter. Min.8V can
start up the controller
Charging status
LED indicator Fast
flashing
Battery Over
Voltage
Check if battery voltage is
higher than OVD, and
disconnect the PV
LED1 Fast flashing
Battery
over discharged
When the battery voltage is
restored to or above LVR point
(low voltage reconnect
voltage), the load will recover
Load status LED
indicator slowly
flashing
Load over load
①
①Please reduce the number of
electric equipments .
②Press the button or repower
the controller.
Load status LED
indicator fast
flashing
Load short circuit
①Check carefully loads
connection, clear the fault.
②Press the button or repower
the controller.
①When load current reaches1.25 times 1.5 times and 2 times 1.35-1.5 times
more than nominal value, the controller will automatically turn off loads in 60s,
5s and 1s respectively.
9. Technical Specifications
Item
MP-3750
MP-3752
Nominal system voltage
12/24VDC Auto
Rated charge current
10A
20A
Rated discharge current
10A
20A
Battery input voltage range
8V～32V
Max. PV open circuit voltage
50V
Self-consumption
12V≤5mA; 24V≤7mA
Charge Circuit Voltage Drop
≤0.13V
Discharge Circuit Voltage Drop
≤0.17V
Temperature compensation
coefficient
-5mV/ ºC /2V
USB Output Port
5VDC/1.2A
Working environment
temperature
-35 ºC ～ +55 ºC
Humidity
≤95% N.C.
Enclosure
IP20
Grounding
Common Positive
Overall dimension
120.3x67x
21.8mm
148x85.6x
34.8mm
Mounting dimension
111.5mm
138mm
Mounting hole size
Φ4.5
Terminals
12AWG/4mm
2
10AWG /6mm
2
Net weight
0.10kg
0.18kg
Battery Voltage Control Parameters
Below parameters are in 12V system at 25 ºC, please double the values in
24V system
Battery Type
Sealed
Gel
Flooded
Over Voltage Disconnect Voltage
16.0V
16.0V
16.0V
Charging Limit Voltage
15.0V
15.0V
15.0V
Over Voltage Reconnect Voltage
15.0V
15.0V
15.0V
Equalize Charging Voltage
14.6V
——
14.8V
Boost Charging Voltage
14.4V
14.2V
14.6V
Float Charging Voltage
13.8V
13.8V
13.8V
Boost Reconnect Charging Voltage
13.2V
13.2V
13.2V
Low Voltage Reconnect Voltage
12.6V
12.6V
12.6V
Under Voltage Warning Reconnect
Voltage
12.2V
12.2V
12.2V
Under Voltage Warning Voltage
12.0V
12.0V
12.0V
Low Voltage Disconnect Voltage
11.1V
11.1V
11.1V
Discharging Limit Voltage
10.6V
10.6V
10.6V
Equalize Duration
120 min.
——
120 min.
Boost Duration
120 min.
120 min.
120 min.
10. Disclaimer
This warranty does not apply under the following conditions:
 Damage from improper use or use in an unsuitable environment.
 PV or load current, voltage or power exceeding the rated value of controller.
 User disassembly or attempted repair the controller without permission.
 The controller is damaged due to natural elements such as lighting.
 The controller is damaged during transportation and shipment.
11. Package Contents
MP-3750 / MP-3752 charge controller
User manual
Distributed by:
TechBrands by Electus Distribution Pty. Ltd.
320 Victoria Rd, Rydalmere
NSW 2116 Australia
Ph: 1300 738 555
Int’l: +61 2 8832 3200
Fax: 1300 738 500
www.techbrands.com
Made in China
Any changes without prior notice! Version number：V1.8
