PowerTech PL500E - Gate Opener Installation; Standard Installation Demonstration; Description of Device

2.1 Standard Installation Demonstration
1. 24V DC sliding motor
2. Transmitter
3. Safety photo sensor
4. Flashing light
a. Operation gear
b. Limit switch device
c. 24Vdc motor
d. Back-up batteries (Optional)
e. Release device
f. Control panel
g. Terminals of devices
h. Green Box (Optional)
2. Installation:
3
4
2
3
e
h
f
g
a
b
c
d
2.2 Description of Device
INSTRUCTIONS PL300E/PL400E/PL500E/PL800E SLIDING GATE OPENER USER MANUAL
3
1
