12V(12.8V) 400Ah battery system
Connect in Parallel
Connect in Series
Note
48V(51.2V) 100Ah battery system
When you connect batteries in series, the voltage increases
while the amperage (ampere) remains the same.
For example, if you connect two 12.8V 100Ah batteries in
series, the battery system's voltage will be 25.6V, and the
capacity remains at 100Ah.
For example, if you connect two 12.8V 100Ah batteries in
parallel, the battery system's voltage remains at 12.8V, and
the capacity will be 200Ah.
Note
When you connect batteries in parallel, the ampere increases
while the voltage remains the same.
Up to 16 identical batteries connection： 4 in series for 48V
(51.2V) & 4 parallel for 400Ah battery systems in total.
Restrictions
