Model Name BT5120
Battery Cell
Series-parallel
3.2V/100Ah（LiFePO4）
16S1P, 51.2V/ 100 Ah total.
Rated Power
5120Wh
Service Life 6000+ (to 80% DoD.)
Charging Current 20A-50A
Charging Voltage 56.8 - 58.4V
Charging Mode
Constant Current (CC)
Constant Voltage (CV)
Operating Temperature
Charge: 0-45°C
Discharge:-20-60°C
Discharge current 50A
Max. Discharge current 100A
Net Weight 86lbs / 39.05KG
Size 20.4”*10.6”*8.7” / 522*270*221 mm
1. Technical Specification
