CAPSTAN POWERED LIFT ASSIST POWERWINCH
2
SPECIFICATIONS
Davit/Bow Roller
This product requires the use of a closed loop davit or bow roller. Davit or bow roller
must be installed prior to installing winch to ensure proper performance.
WARNING Use of a davit with an open loop is not
recommended with this product. Use a davit with a closed loop to prevent
serious personal injury and/or property damage.
6 7/16"
7 1/8"
8 5/16"
10 5/8"
pwcs004
Model
Maximum
Pull Rope Size* Voltage
Circuit
Breaker
Unit
Weight
Capstan 1000 1000 lbs. 1/2-3/4" 12VDC 80 amps 23 lbs.
Capstan 300 300 lbs. 1/2-5/8" 12VDC 25 amps 20 lbs.
Quick Catch Pot Puller 200 lbs. Up to 5/8" 12VDC 80 amps 19 lbs.
* Recommended rope is three (3) strand, medium lay, premium nylon.
CAUTION ALWAYS use the recommended rope. Use of different rope
can cause property damage and personal injury.
