POWERWINCH CAPSTAN POWERED LIFT ASSIST
3
FURNISHED MATERIALS:
Capstan 1000 Capstan 300 Quick Catch Pot Puller
qty Description qty Description qty Description
1 Winch 1 Winch 1 Winch
3 5/16-18 x 3.5 Stud 3 5/16-18 x 3.5 Stud 3 5/16-18 x 3.5 Stud
3 5/16 Lock Washer 3 5/16 Lock Washer 3 5/16 Lock Washer
3 5/16 Flat Washer 3 5/16 Flat Washer 3 5/16 Flat Washer
3 5/16-18 Nut 3 5/16-18 Nut 3 5/16-18 Nut
1 80A Circuit Breaker 1 25A Circuit Breaker 1 80A Circuit Breaker
1 Foot Switch 1 Foot Switch 1 Foot Switch
1 Mounting Template 1 Mounting Template 1 Mounting Template
REQUIRED MATERIALS (NOT INCLUDED WITH WINCH)
• Loctite 242 thread locker or equivalent
• Silicone sealant
E
LECTRICAL INSTALLATION – CAPSTAN 1000 & QUICK CATCH POT PULLER
These items are furnished by the installer.
Qty Description
6 awg RED Wire Class 105˚C Wire is used for the "run" wire from winch to
switch, battery to switch and battery to winch.
Length is based on installation.
6 awg BLACK Wire
7 5/16" 6 awg ring terminals
5 1/4-20 x 1/2 Screws Screws and nuts should be stainless
steel to avoid rust and corrosion.
5 1/4-20 Nuts
a/r Wire ties
2 ft 1" diameter heat shrink
2 ft 2" diameter heat shrink
E
LECTRICAL INSTALLATION – CAPSTAN 300
These items are furnished by the installer.
Qty Description
8 awg RED Wire Class 105˚C Wire is used for the "run" wire from winch
to switch, battery to switch and battery to
winch. Length is based on installation.
8 awg BLACK Wire
7 5/16" 8 awg ring terminals
5 1/4-20 x 1/2 Screws Screws and nuts should be stainless
steel to avoid rust and corrosion.
5 1/4-20 Nuts
a/r Wire ties
2 ft 1" diameter heat shrink
2 ft 2" diameter heat shrink
