V. General Specifications
Dimensions: 0.85 meters wide x 0.95 meters high x 0.57 meters deep
(33.4” x 37.4” x 22.4”)
Dry weight: 100 kg. (220 lbs.)
Fluid capacity: 55 liters (14.5 gallons)
Power supply: 220/240 volt, 1 phase, 50/60 Hz
Current: 20 amperes max
Electrical Plug: NEMA Type 6-20P (250 V, 20 A)
Mating Recept.: NEMA Type 6-20R (250 V, 20 A)
Filters: Spun Polypropylene - 5 micron, 20" Size (2 required)
O-Rings: Filter Housing O-Ring: Buna-N (3 required)
Noise: Less than 75 dB
Ultrasonics: 750 Watt, 40 KHz
Dryer: 530 CFM @ 0.45” Water SP; 1500 Watt heater
Fluid Heater: 312 Watt
