224-231 Reverse rotation speed 4
232-239 Reverse rotation speed 3
240-247 Reverse rotation speed 2
248-255 Reverse rotation speed 1 (slowest)
000-051 White
052-102 Prism 1
103-153 Prism 2
154-204 CTO
10 Prism Wheel
205-255 Frost
000-120 0~540º index
121-127 Rotation speed 1
128-135 Rotation speed 2
136-143 Rotation speed 3
144-151 Rotation speed 4
152-159 Rotation speed 5
160-167 Rotation speed 6
168-175 Rotation speed 7
176-183 Rotation speed 8
184-191 stop rotating
192-199 Reverse rotation speed 8
200-207 Reverse rotation speed 7
208-215 Reverse rotation speed 6
216-223 Reverse rotation speed 5
224-231 Reverse rotation speed 4
232-239 Reverse rotation speed 3
240-247 Reverse rotation speed 2
11 Prism Rotation
248-255 Reverse rotation speed 1
12
Pan & Tilt Speed
000-255 Adjust Pan&Tilt speed
13
Pan Fine (16Bit) （ext. channel）
000-255 Adjust Pan in 16Bit resolution
14
Tilt Fine (16Bit)
（ext. channel）
000-255 Adjust Tilt in 16Bit resolution
15
Gobo Rotation Fine
（ext. channel）
000-255 Adjust gobo rotation in 16Bit resolution
000-048 Reserve
049-080 Reset
081-112 Reserve
113-144
Turn lamp off（stay 10 seconds）
145-223 Reserve
16
Control
(when ext. channels
disabled, this channel
performed by channel 12)
224-255
Turn lamp on（see remark below）
Remark:
If you intend to turn on/off the lamp via the 16
th
channel of the controller, don’t attempt to push the fader of 16
th
channel to
value 224-255 immediately after turning it off, or push the fader to value 224-255 to wait it cooling. Under these 2
circumstances, the lamp can not be turned on. The right operation is: turn it off---cool down---push the fader to turn it on.
