PR 4104 - Error Readout and Hardware Errors

14 4104 V100-UK
4501 display readout of input 4-20 mA loop error detection and
signal ”outside range”
Input loop error check:
Device: Configuration Input loop error detection
4104
OUT.ERR=NONE. OFF
OUT.ERR=DOWN,UPandZERO ON
Input ”outside range” limits - readout (IN.LO, IN.HI):
Input Ranges Readout Limit
CURR All - unipolar and bipolar
IN.LO <-23mA
IN.HI >23mA
VOLT All - unipolar and bipolar
IN.LO <-12V
IN.HI >12V
Input loop error detection - readout (LO.ER):
Input Range Readout Limit
CURR 4..20 mA LO.ER <=3.6mA;>=21mA
Display readout below min.- / above max. (-1999, 9999):
Input Range Readout Limit
All All
-1999 Displayreadout<-1999
9999 Displayreadout>9999
Readout at hardware error
Error search Readout Error caused by
Check measurement of analogue output - read * note AO.ER
No load on the current output
(only S4...20 mA)
Communications test 4501 / 4104 NO.CO Connection error
Hardware error - read ** note FL.ER Error in FLASH
Configuration error - read ** note CO.ER Error in FLASH
Check that saved configuration in 4501 matches device TY.ER Invalid type or rev. no
Hardware error - read * note AO.SU Analogue output supply err.
Hardware error - read * note RA.ER RAM error
Hardware error - read * note EE.ER EEPROM error
Hardware error - read * note AD.ER A/D converter error
Hardware error - read * note IF.ER Flash check sum error
! All error indications flash (1 Hz), and the corresponding helptext is shown.
If the error is an input loop error, the display backlight flashes as well - this is
acknowledged (stopped) by pushing the OK button.
* Error is acknowledged by either stepping through the basic setup, or by
resetting the device power.
Some types of errors can only be acknowledged by resetting the device power.
** Error is acknowledged by stepping through the basic setup.
