Auxiliary supply:
2-wire supply (pin 46...45) ....................... 25...15 VDC / 0...20 mA
Wire size, pin 41...46 (max.) ........................ 1 x 1.5 mm
2
stranded wire
Wire size, others (max.) ............................... 1 x 2.5 mm
2
stranded wire
Relative humidity ......................................... < 95% RH (non cond.)
Dimensions (HxBxD) ................................... 48 x 96 x 120 mm
Cutout dimensions ...................................... 44.5 x 91.5 mm
Protection degree (mounted in panel) ......... IP65 / Type 4X, UL50E
Weight ......................................................... 260 g
RTD, linear resistance and potentiometer input:
Input for RTD types:
Pt10, Pt20, Pt50, Pt100, Pt200, Pt250, Pt300, Pt400, Pt500, Pt1000
Ni50, Ni100, Ni120, Ni1000, Cu10, Cu20, Cu50, Cu100
EMC immunity influence ..................................... < ±0,5% of reading
Basic values
Input
type
Basic
accuracy
Temperature
coefficient
mA ≤ ±4 µA ≤ ±0.4 µA / °C
Volt ≤ ±20 µV ≤ ±2 µV / °C
Pt100 ≤ ±0.2°C ≤ ±0.01°C / °C
Linear resistance ≤ ±0.1 Ω ≤ ±0.01 Ω / °C
Potentiometer ≤ ±0.1 Ω ≤ ±0.01 Ω / °C
TC type:
E, J, K, L, N, T, U
≤ ±1°C
≤ ±0.05°C / °C
TC type: R, S, W3,
W5, LR
≤ ±2°C
≤ ±0.2°C / °C
TC type: B
160...400°C
≤ ±4.5°C
≤ ±0.45°C / °C
TC type: B
400...1820°C
≤ ±2°C
≤ ±0.2°C / °C
Input
type
Min.
value
Max.
value
Standard
Pt10...Pt1000
Ni50...Ni1000
Cu10...Cu100
Lin. R
Potentiometer
-200°C
-60°C
-200°C
0 Ω
10 Ω
+850°C
+250°C
+260°C
10000 Ω
100 kΩ
IEC 60751
DIN 43760
α = 0.00427
-
-
