REPLACING THE BATTERY
1. Undo the screw and remove the bottom cover.
2. Replace the old batteries with 2 new
1.5V AAA
batteries (Order Code
L42AL).
3. Replace the bottom cover and tighten the screw.
REPLACING THE FUSE
1.Disconnect the test leads from the meter.
2.Remove the test leads holder and top cover screw.
3.Lift the center circuit board straight up from the connectors to
gain access to the fuse holders.
4. Remove the old fuse and place the new fuse into the holder.
5.Always use a fuse of the proper size and value (0.2A/250V fast
blow for the 200mA range).
6.Align the center board with the connectors and gently press into place.
7.Replace and secure the rear cover and screw.
WARNING: To avoid electric shock, do not operate your meter
until the fuse cover is in place and fastened securely.
