5
Batteries: Two 1.5V AAA
Operating Temperature: 0
o
C to 40
o
C (32
o
F to 104
o
F)
Storage Temperature: -10
o
C to 50
o
C (14
o
F to 122
o
F)
Weight: 145g
Size: 104 x 55 x 32.5mm
Standard: IEC61010 CAT III 1000V Pollution degree II, CE
Approved
Operation
AC/DC VOLTAGE MEASUREMENTS
CAUTION: Do not measure AC/ DC voltages if a motor on the
circuit to be measured is being switched ON or OFF. Large
voltage surges may occur that can damage the meter.
1. Set the function switch to the green V position.
2. Press the MODE button to indicate “DC” or “AC” on the
display.
3. Place the black test probe tip to the negative side of the
circuit.
Place the red test probe tip to the positive side of the circuit.
4 . Read the voltage in the display
DC/AC CURRENT MEASUREMENTS
1. Set the function switch to the µA/mA position.
2. For current measurements up to 2000µA DC/AC, set the
function switch to the mA position
3. Press the MODE button to indicate “DC” / “AC” on the
display.
4. Remove power from the circuit under test, then open up the
circuit at the point where you wish to measure current.
5. Place the black test probe tip to the negative side of the
circuit.
Place the red test probe tip to the positive side of the circuit.
6. Apply power to the circuit.
7.
Read the current in the display
