Precision 280 Series - Typical Bottom View Diagram

16
ON/OFF
SWITCH
PCB ASSEMBLY
TYPICAL BOTTOM VIEW
POWER
HARNESS
HEATER
HARNESS
HEATER
HEATER
INSULATOR
POWER LINE
CORD
THE FLAT SIDE OF THE
SENSOR MUST COME IN
CONTACT WITH THE PAN
TEMPERATURE
PROBE ASSEMBLY
