17
TEMPERATURE SENSOR
POWER LINE
CORD
DETAIL "A"
POWER
HARNESS
PCB
ASSEMBLY
HEATER
HEATER
HARNESS
POWER
SWITCH
120 VAC WIRING DIAGRAM
NOTE: JP3 & JP4 MUST BE INSTALLED FOR 120 VAC OPERATION.
