18
POWER LINE
CORD
POWER
SWITCH
TEMPERATURE SENSOR
PCB
ASSEMBLY
HEATER
HARNESS
HEATER
POWER
HARNESS
DETAIL "A"
NOTE: JP3 & JP4 MUST BE REMOVED FOR 230VAC OPERATION
230 VAC WIRING DIAGRAM
