©2019 Precor Inc. | Diverging Lat Pulldown RSL 314 | Assembly Guide
4
Parts List
Part #
Name
Quantity Part #
Name
Quantity
Main frame
1
Shroud, front middle (left and right)
2
Arm, left
1
Top tray
1
Arm, right
1
Shroud, lower pulley cover
1
Seat assembly
1
Seat pad
1
Thigh adjustment bar
1
Roller pads
2
Upper cross brace
1
Weight plates 10 lb (4.5 kg)
23
Lower cross brace
1
Weight labels
1
Roller pad ring caps
2
Collars
2
Roller pad caps
2
End plugs with sleeves
2
Shaft, 19 mm x 136 mm
1
Roller adjustment tool (part of Seat assembly )
1
Bumpers
4
Washers, 12.2 mm ID x 35 mm OD
2
Shaft, 19 mm x 127 mm
1
Washers, rubber, black
3
Roller assembly
1
Washers, domed, silver
2
Gas spring
1
Retaining rings, medium
2
Weight stack tower frame
1
Washer, silver, 13.5 mm ID x 35 mm OD
1
Weight stack spacer, 1-inch
1
Retaining rings, small
2
Add-on weight spacer, 3-inch
1
Socket head cap screws (SHCS) M12 x 25 mm
2
Top plate assembly
1
Socket head cap screws (SHCS) M12 x 35 mm
6
Add-on weight 5 lb (2.2 kg)
1
Socket head cap screws (SHCS) M12 x 130 mm
2
Add-on weight handle
1
Socket head cap screws (SHCS) M10 x 25 mm
2
Kick plate
1
Socket head cap screws (SHCS) M10 x 40 mm
2
Guide rods
2
Socket head cap screws (SHCS) M10 x 65 mm
2
Shroud, crown
1
Button head cap screws (BHCS) M10 x 125 mm
2
Guide rod with cap
1
Button head cap screw (BHCS) M6 x 15 mm
1
Counterweight
1
Hex head screws 5/16-inch x 1½-inch
4
Shroud, rear upper
1
Nylon lock nuts, M12
2
Shroud, front upper placard
1
Nylon lock nuts, M10
2
Shroud, front lower
1
Washers, 9 mm
4
Shroud, rear lower
1
Washers, 13 mm
8
Shroud, rear middle
1
Washers, 11 mm
4
1
10
11
12
13
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3
30
31
32
33
34
35
36
37
39
4
40
42
43
44
45
46
47
48
49
6
7
8
9
2
5
14
38
41
50
51
52
53
54
55
56
57
58
59
60
4
