Secure axle plate with mounting plate bolts and carefully return bike to the upright
position.
11. Position the flywheel to align the left and right axle mounting plate holes to the frame
mounting threads. Secure axle mounting plate with fasteners (2x each) using a 6
mm hex key.
12.
Tighten the left and right axle bolts , torque to 29.5 ft-lbs (40 Nm).
13.
Reinstall the frame cross member onto frame, make sure the drive belt is correctly
installed onto the tension mechanism pulleys. Secure with fasteners (4x) using 6 mm
hex key.
14.
Reinstall the rear belt pulley finger guard , secure with the fasteners (2x) using a 5
mm hex key.
15. Tension belt to specification, go to "Belt Drive Tension Adjustment" on page9.
NOTE:Make sure the frame cross member is installed before tensioning belt.
16. Verify that the brake pad is centered on the flywheel and operating correctly.
17. Replace front and rear belt guard covers, see "Belt/Chain Guard Cover Replacement"
on page18
18. Verify the bike operation per "Operation Verification Checklist" on page7 and return to
service.
See Also
"Replacement Procedures" on page16
23
