Precor SPINNER SHIFT User Manual

.
3.
Remove the brake pad by removing the one mounting bolt using a 3 mm hex key.
Retain fastener hardware for installation.
Installation Instructions
4.
Reinstall the brake pad onto the assembly and secure with the mounting bolt.
5.
Pull up the resistance knob and slide the brake pad assembly into position aligning
the frame mounting bolt inserts. Secure using the two 5 mm hex hey mounting bolts (2x)
and washers (2x). Make sure that the brake pad is centered on the flywheel rim and fully
tighten.
25
