14. Adjust the chain tension to specification, go to "Chain Drive Tension Adjustment" on
page11
15.
Tighten the left and right axle nuts , torque to 29.5 ft-lbs (40 Nm).
16.
Reinstall the rear chain sprocket finger guard , secure with two fasteners using a 5
mm hex key.
17. Replace front and rear chain guard covers in reverse order, see "Belt/Chain Guard
Cover Replacement" on page18.
18. Verify that the brake pad is centered on the flywheel and operating correctly.
19. Verify the bike operation per "Operation Verification Checklist" on page7 and return to
service.
.See Also
"Replacement Procedures" on page16
29
