Page 20 For technical questions, please call 1-800-520-0882.
ITEM 69727 / 69730
Parts Lists and Diagrams
69727 Parts List
Part Description Qty
1 Gasket, Cylinder Head 1
2 Cover Subassembly, Cylinder Head 1
3 Gasket, Cylinder Head Cover 1
4 Tube, Breather 1
5 Bolt 4
6 Stud 2
7 Stud 2
8 Pin 2
9 Bolt, Cylinder Head 4
10 Plug, Spark 1
11 Head Subassembly, Cylinder 1
12 Crankcase Subassembly 1
13 Sensor, Engine Oil 1
14 Gear Asm, Governor 1
15 Arm, Governor 1
16 Bolt, Drain Plug 2
17 Washer, Flat 2
18 Bearing, Deep Groove Ball 2
19 Seal, Oil 1
20 Washer, Flat 1
21 Cotter 1
22 Bolt 2
23 Cover, Crankcase 1
24 Gasket, Crankcase 1
25 Pin 2
26 Dipstick Subassembly, Oil 1
27 Plug Subassembly, Engine Oil 1
28 Seal, Oil 1
29 Bolt 6
30 Crankshaft Asm. 1
31 Clip, Piston Pin 2
32 Piston 1
33 Pin, Piston 1
34 Rod, Connecting 1
35 Primary Ring 1
36 Secondary Ring 1
37 Ring Set, Oil 1
38 Camshaft Asm. 1
39 Valve, Exhaust 1
40 Valve, Intake 1
41 Seat, Valve Spring 2
42 Clamp, Valve Lock 4
43 Guide, Seal 2
44 Spring, Valve 2
45 Plate Subassembly, Lifter Stopper 1
46 Bolt, Rocker Shaft 2
47 Rocker, Valve 2
Part Description Qty
48 Nut, Valve Adjusting 2
49 Nut, Valve Lock 2
50 Tappet, Valve 2
51 Lifter, Valve 2
52 Starter Asm, Recoil 1
53 Bolt 1
54 Shroud 1
55 Bolt 4
56 Shroud, Cylinder Body 1
57 Bolt 2
58 Shield,Lower 1
59 Bolt 1
60 Protector, Oil 1
61 Collar 1
62 Switch Subassembly, Stop Engine 1
63 Gasket, Carburetor Insulator 1
64 Plate, Carburetor Insulator 1
65 Gasket, Carburetor 1
66 Gasket, Air Cleaner 1
67 Nut 2
68 Cleaner, Air 1
69 Gasket, Exhaust Outlet 1
70 Nut 2
71 Muffler Asm. 1
72 Tank, Fuel 1
73 Strainer, Fuel 1
74 Cover, Fuel Tank 1
75 Outlet Subassembly, Fuel Tank Oil 1
76 Collar 1
77 Tube, Fuel 1
78 Jacket, Rubber 1
79 Nut 2
80 Nut, Flywheel 1
81 Pulley, Starter 1
82 Impeller 1
83 Flywheel Subassembly 1
84 Bolt 2
85 Coil, Ignition 1
86 Support Subassembly, Governor 1
87 Nut 1
88 Bolt, Governor Support 1
89 Spring, Governor 1
90 Rod, Governor 1
91 Spring, Throttle Valve Returning 1
92 Control Asm, Throttle 1
93 Bolt 2
