Page 22 For technical questions, please call 1-888-866-5797. 301cc Engine
SAFETY OPERATION MAINTENANCESETUP
Mounting Hole Diagram
Note: Not to scale.
7.69" / 195.5mm
6.12" / 155.5mm
3.78" / 95.5mm
0.51" / 13mm
0.47" / 12mm
