Predator Engines 420cc - Parts and Diagrams; Parts List

Page 20 For technical questions, please call 1-800-520-0882. ITEM 69736
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
Parts List
Part Description Qty.
1 Gasket, Cylinder Head 1
2 Cover Subassembly, Cylinder Head 1
3 Gasket, Cylinder Head Cover 1
4 Tube, Breather 1
5 Bolt, Cylinder Head 1
6 Washer Set 1
7 Stud 2
8 Stud 2
9 Pin 2
10 Bolt, Cylinder Head 4
11 Plug, Spark 1
12 Head Subassembly, Cylinder 1
13 Crankcase Subassembly 1
14 Seal, Oil 1
15 Sensor, Engine Oil 1
16 Frame, Fuel Tank Installation 1
17 Plug, Rubber 1
18 Protector, Oil 1
19 Bolt 1
20 Washer, Flat 2
21 Bolt, Drain Plug 2
22 Clip 1
23 Arm, Governor 1
24 Seal, Oil 1
25 Cotter 1
26 Bolt 4
27 Bolt 2
28 Washer, Flat 1
29 Bearing, Deep Groove Ball 1
30 Cover, Crankcase 1
31 Gasket, Crankcase 1
32 Plug Subassembly, Engine Oil 1
33 Dipstick Subassembly, Oil 1
34 Pin 2
35 Bolt 7
36 Bearing, Deep Groove Ball 1
37 Gear Asm, Governor 1
38 Seal, Oil 1
39 Bearing, Deep Groove Ball 1
40 Crankshaft Asm. 1
42 Ring Set, Oil 1
43 Clip, Piston Pin 2
44 Piston 1
45 Pin, Piston 1
46 Rod, Connecting 1
47 Ring, The First 1
48 Ring, The Second 1
49 Camshaft Asm. 1
50 Valve, Exhaust 1
51 Valve, Intake 1
52 Seat, Valve Spring 1
53 Retainer, Exhaust Valve 1
54 Rotator, Valve 1
55 Guide, Seal 1
56 Tappet, Valve 2
57 Lifter Subassembly, Valve 2
Part Description Qty.
58 Plate Subassembly, Lifter Stopper 1
59 Bolt, Rocker Shaft 2
60 Rocker, Valve 2
61 Nut, Valve Adjusting 2
62 Nut, Valve Lock 2
63 Spring, Valve 2
64 Retainer, Valve Spring 1
65 Starter Asm, Recoil 1
66 Bolt 3
67 Shroud 1
68 Shroud, Cylinder Body 1
69 Bolt 6
70 Clip 1
71 Carburetor Asm. 1
72 Gasket, Air Cleaner 1
73 Gasket, Carburetor 1
74 Plate, Carburetor Insulator 1
75 Gasket, Inlet 1
76 Nut 2
77 Cleaner, Air 1
78 Muffler Asm. 1
79 Pipe, Exhaust 1
80 Gasket, Muffler 1
82 Gasket, Exhaust Outlet 1
83 Tank, Fuel 1
84 Strainer, Fuel 1
85 Cover, Fuel Tank 1
86 Outlet Subassembly, Fuel Tank Oil 1
87 Clamp 2
88 Tube, Fuel 1
89 Nut 2
90 Nut, Flywheel 1
91 Pulley,Starter 1
92 Impeller 1
93 Flywheel Subassembly 1
94 Bolt 1
95 Clamp, Charge Coil 1
96 Coil Subassembly, Charge 1
97 Bolt 4
98 Coil, Ignition 1
99 Control Asm, Throttle 1
100 Bolt 2
101 Spring, Throttle Valve Returning 1
102 Rod, Governor 1
103 Support Subassembly, Governor 1
104 Nut 1
105 Bolt, Governor Support 1
106 Spring, Governor 1
107 Motor, Starting 1
108 Bolt 2
109 Bolt 2
110 Relay, Starting 1
111 Box, Motor Control 1
112 Bracket, Starting Relay 1
113 Bolt 1
114 Bolt 2
