Predator 57322 - Parts List and Diagram

Page 6 For technical questions, please call 1-888-866-5797. Item 57322
17 17
4
17
17
13
21
17 17
17 17
9
21
21
20
14
21
21
23
18
11
17
20
21
23
3
6
12
15
20
5
17
20
19
16
6
2
5
1
18
17
20
10
3
2
1
21
19
19
17
17
24
24
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List and Diagram
Parts List
Part Description Qty
1 M10 Axle Nut 2
2 M10x20 Axle Washer 2
3 Wheel 2
4 Handle 1
5 Axle 2
6 M12 Nut 2
7 Handle Bracket 1
8 M8x16 Bolt 4
9 M8 Nut 1
10 M8x45 Bolt 1
11 Foot Support 1
12 Axle Support 2
Part Description Qty
13 Crossbar 1
14 Crossbar Bracket 2
15 Lower Bracket 2
16 Upper Bracket 2
17 M6 Nut 22
18 M6x25 Bolt 8
19 M6x30 Wheel Bracket Bolt 12
20 Washer 22
21 Spring Washer 22
22 M8x64 Pin 1
23 M6x15 Short Bolt 2
24 Steel Spacer Washer 2
