Predator 57509 - Parts Lists and Diagrams; Engine Parts List

Page 20
For technical questions, please call 1-888-866-5797.
ITEM 57509
SAFETY OPERATION MAINTENANCESETUP
Parts Lists and Diagrams
Engine Parts List
Part Description QTY
1 Bolt, Flange, M6 x 20 7
2 Cylinder Cover Assy. 1
3 Cylinder Cover Seal Washer 1
4 Hex Flange Face Bolt, M6 x 12 11
5 Shroud 1
6 Spark Plug 1
7 Hex Flange Face Bolt, M8 x 50 2
8 Hex Flange Face Bolt, M8 x 70 2
9 Bolt, Stud, Exhaust 2
10 Exhaust Valve Rotor 2
11 Exhaust Valve Spring Seat 2
12 Spring, Valve 2
13 Oil Shield 1
14 Cylinder Head Assy. 1
15 Bolt, Stud, Inlet 2
16 Rocker Arm Shaft Adjusting Nut 2
17 Rocker Shaft 2
18 Rocker Arm 2
19 Rocker Shaft Bolt 2
20 Push Rod Guide 1
21 Cylinder Head Seal Washer 1
22 Dowel Pin 2
23 Valve, Exhaust 1
24 Valve, Intake 1
25 Push Rod 2
26 Lifter, Valve 2
27 Ring Set, Piston 1
28 Clip, Piston Pin 2
29 Piston 1
30 Pin, Piston 1
31 Connecting Rod Assy. 1
32 Hex Flange Bolt, M10 x15 2
33 Aluminum Washer 2
34 Crankcase 1
35 Engine Oil Sensor 1
36 Hex Flange Bolt, M6 x 16 7
37 Bearing 2
38 Oil Seal 2
39 Alternator Stator 1
40 Rubber Stopper 4
41 Oil Alert 1
Part Description QTY
42 Shroud 1
43 Hex Flange Bolt, M6 x 28 2
44 Coil Assy, Ignition 1
45 Alternator Rotor 1
46 Cooling Fan 1
47 Pulley, Starter 1
48 Disc Nut, M14 1
49 Cover Comp, Pan 1
50 Cover, Recoil Starter 1
51 Oil Plug 1
52 Crankcase Cover 1
53 Dipstick Assy. 1
54 Dowel Pin 6
55 Crankcase Cover Seal Washer 1
56 Camshaft Assy. 1
57 Crankshaft Assy. 1
58 Gasket, Air Intake 1
59 Insulator, Carburetor 1
60 Carburetor Washer 1
61 Carburetor Assy. 1
62 Gasket, Air Cleaner 2
63 Zip Support, Carburetor 1
64 Stepper Motor Support 1
65 Tube, Fuel 1
66 Clip, Tube 1
67 Protective Sleeve 1
68 Air Cleaner Assy. 1
69 Waste Pipe 1
70 Clip, Tube 1
71 Metal Clip 1
72 Hex Socket Head Screw, M6 x 55 4
73 Hex Flange Bolt, M8 x 32 7
74 Hex Flange Nut, M6 5
75 Start Cup Connection Plate 1
76 Inverter Cover 1
77 Hex Flange Bolt, M6 x 50 4
78 Clip, Check Valve 1
79 Hex Flange Bolt, M8 x 16 4
80 Cross Grooved Disc Head Screw, M4 x 8 2
81 Stepper Motor Support 1
82 Cross Grooved Disc Head Screw, M4 x 5 2
