Page 22
For technical questions, please call 1-888-866-5797.
ITEM 57509
SAFETY OPERATION MAINTENANCESETUP
Generator Parts List
Part Description
1 Flange Bolt
2 Inverter Rear Cover
3 Inverter Module
4 Engine
5 Clamp
6 Clamp
7 Breather
8 Fuel Valve
9 Pad
10 Fuel Tank Assy.
11 Flange Bolt
12 Tank Gasket
13 Nut
14 Spring Washer
15 Muffler Gasket
16 Muffler Assembly
17 Control Panel Assembly
18 Bumper
19 Cross Pan Head Screw
20 Flange Nut
21 Pull Rope Guard
Part Description
22 Bracket
23 Flange Bolt
24 Ground Wire
25 Toothed Washer
26 Flange Nut
27 Frame Damping Pad
28 Damper Cable Assembly
29 Air Filter Support Block
30 Damping Support
31 Flange Nut
32 Mounting Plate
33 Mounting Plate
34 Damping Seat
35 Flange Bolt
36 Flat Washer
37 Flange Bolt
38 Frame Assy.
39 Harness
40 Cross Pan Head Screw
41 Mounting Bracket
42 Carbon Monoxide Alarm
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175415431 when ordering parts.
