Page 8 For equipment technical questions, please call 1-888-866-5797. Item 58028
SAFETY SETUP OPERATION MAINTENANCE
5. Connect Pressure Hose to Pump’s
Outlet and firmly hand-tighten.
6. Connect Pressure Hose to Spray Gun Handle
and firmly hand-tighten.
7. Remove protective cap on Wand Inlet.
Insert Wand into Spray Gun Outlet
and firmly hand-tighten.
8. Attach Nozzle to Wand by pulling back
quick-connect collar and pushing Nozzle
onto Wand. Make sure quick-connect
collar locks Nozzle in place.
9. Connect water supply hose to Pump’s Inlet and
firmly hand-tighten.
Note: The water source must be able to provide
a minimum of five gallons of clean, cold water per
minute at 20 PSI. Only use a 5/8" inner diameter
(or larger) hose that is rated to meet this capacity.
Spray Gun
Outlet
Wand
Inlet
Quick Connect
Collar
Wand
Nozzle
Water
Supply
Hose
Inlet
Assembly (continued)
To Next Page
