Page 13
For technical questions, please call 1-888-866-5797.
ITEM 59137
SAFETYOPERATIONMAINTENANCE SETUP
Electric Start
1. Move the Economy (ESC)
Switch to the OFF position.
2. Turn the Combination Switch
to the START position.
3. Press and hold the Starter Button
to start the Engine. If Engine
does not start within 3 seconds,
release Starter Button. Wait at
least 10 seconds, then try again.
Note: If engine does not start, check
engine oil level. Engine will not
start with low or no engine oil.
Note: If warm engine does not start,
turn Combination Switch to RUN
before trying to start it again.
4. The OUTPUT light illuminates when
the Engine starts and the Generator
produces power. Allow the Engine
to run for several seconds, then
move the Combination Switch
slowly to its RUN position.
Note: Moving the Combination
Switch too fast could stall the Engine.
IMPORTANT: Allow the Engine to run
at no load for five minutes after each start-up
so that the Engine can stabilize.
2
1
3
4
