Page 7For technical questions, please call 1-888-866-5797.ITEM 59190
SAFETYSETUPOPERATIONMAINTENANCE
Functional Description
Specifications
Generator
Output
120 / 240 VAC, 60 Hz, 58.3 / 29.2 A, 1 Phase
7,000 Running Watts (8,750 max. starting Watts)
12VDC, 8.3A
5V USB, 3.1A
Battery for electric start 12V, 1.6AH Lithium Iron Phosphate (LiFEPO4)
Electrical Receptacle
Two 3-Prong, duplex NEMA #5-20 120 V GFCI
One 4-Prong, NEMA #L14-30 twistlock 120 V / 240 V
One DC Outlet 12 VDC
2X USB-A Ports
Engine
Displacement 420 cc
Engine Type Horizontal Single Cylinder 4 stroke OHV
Cooling System Forced air cooled
Fuel
Type 87+ octane stabilizer treated unleaded gasoline
Capacity 5.94 Gallon / 22.50 Liter
Engine Oil
Type SAE
10W – 30 above 32° F
5W – 30 at 32° F or below
Capacity 1.1 Quart
Spark Plug
Type NHSP
®
/ LG F7TC
Gap 0.028" – 0.031"
Valve Clearance Intake/Exhaust 0.0019″ - 0.0039″
Run Time @ 25% load 15.1 hr.
Operational Volume 75 dB(A) @ 21 ft., 25% load
The emission control system for this Generator’s Engine is warranted for standards set by the U.S. Environmental
Protection Agency and by the California Air Resources Board (also known as CARB). For warranty information,
refer to the last pages of this manual.
Components and Controls
Fuel Cap
Battery
Holder
Oil Drain Oil Fill
Muffler
Control
Panel
Receptacles
Fuel Gauge
Starter
Handle
Fuel
Valve
Air Cleaner
