Predator 59205 - Parts List and Diagram

Page 24 For technical questions, please call 1-888-866-5797. ITEM 59205
SAFETY SETUP OPERATION MAINTENANCE
Parts List and Diagram
Parts List
Part Description Qty
1 Cover Subassembly, Cylinder Head 1
2 Bolt 4
3 Tube, Breather 1
4 Gasket, Cylinder Head Cover 1
5 Bolt 1
6 Pin Limit Plate, Cylinder Head Cover 2
7 Rocker, Valve 2
8 Rocker Shaft Valve Assembly 2
9 Seat, Valve Spring 2
10 Spring, Valve 2
11 Guide, Seal 1
12 Shroud, Cylinder Body 1
13 Bolt 1
14 Bolt, Cylinder Head 4
15 Bolt 2
16 Head Subassembly, Cylinder 1
17 Bolt 2
18 Gasket, Inlet 1
19 Plate, Carburetor Insulator 1
20 Gasket, Carburetor 1
21 Carburetor Assy. 1
22 Gasket, Air Cleaner 1
23 Clip 1
24 Cleaner, Air 1
25 Nut 2
26 Plug, Spark 1
27 Gasket, Cylinder Head 1
28 Pin 2
29 Valves Set 1
30 Ring Assy, Piston 1
31 Clip, Piston Pin 2
32 Piston 1
33 Pin, Piston 1
34 Rod, Connecting 1
35 Lifter Subassembly, Valve 2
36 Tappet, Valve 2
37 Bolt, Drain Plug 2
38 Washer, Flat 2
39 Coil, Ignition 1
40 Bolt 2
41 Flywheel Subassembly 1
42 Impeller 1
43 Pulley,Starter 1
44 Nut, Flywheel 1
45 Shroud 1
46 Bolt 5
47 Starter Assy, Recoil 1
48 Bolt 3
49 Seal, Oil 1
50 Plug, Rubber 1
51 Protector, Oil 1
52 Bolt 1
53 Arm, Governor 1
54 Washer, Flat 1
55 Pin 1
56 Spring, Throttle Valve Returning 1
57 Rod, Governor 1
Part Description Qty
58 Support Subassembly, Governor 1
59 Bolt, Governor Support 1
60 Nut 1
61 Spring, Governor 1
62 Control Assy, Throttle 1
63 Bolt 1
64 Nut 1
65 Sensor, Engine Oil 1
66 Bolt 2
67 Crankcase Subassembly. 1
68 Gasket, Exhaust Outlet 1
69 Bolt 2
70 Pipe, Exhaust 1
71 Nut 2
72 Gasket, Exhaust Outlet 1
73 Cover, Muffler Outer 1
74 Bolt 7
75 Muffler Assy. 1
76 Cover, Muffler Side 1
77 Cover, Muffler Inner 1
78 Cushion, Muffler Insulator Rubber 1
79 Bracket,Muffler 1
80 Bolt 2
81 Bolt 2
82 Camshaft Assy. 1
83 Crankshaft Assy. 1
84 Pin 2
85 Gasket, Crankcase 1
86 Bearing, Deep Groove Ball 1
87 Gear Assy, Governor 1
88 Dipstick Subassembly, Oil 1
89 Cover, Crankcase 1
90 Seal, Oil 1
91 Bolt 7
92 Nut, Stator 2
93 Washer, Flat 2
94 Motor Assy. 1
95 Shroud, Motor 1
96 Bolt 1
97 Brush Subassembly, Carbon 1
98 Bolt 5
99 Block, Terminal 1
100 Stopper, Motor Right Cover 1
101 Bracket, Motor 1
102 Bolt 1
103 Washer, Flat 1
104 Bolt, Stator 4
105 Bolt, Rotor 1
106 Bolt, Stator 2
107 Regulator, Voltage 1
108 Cover, Motor Tail 1
109 Bolt 2
110 Tank, Fuel 1
111 Sleeve, Fuel Tank Rubber 4
112 Bush 4
113 Washer, Flat 4
114 Bolt 4
