Part Description Qty
1 Cylinder Head Cover Bolt 1
2 Cylinder Head Cover Bolt Gasket
+ Washer Subassembly
1
3 Cover Subassembly, Cylinder Head 1
4 Cylinder Head Cover Gasket 1
5 Tube, Breather 1
6 Rotator, Valve 1
7 Retainer, Exhaust Valve 1
8 Spring, Valve 2
9 Retainer, Valve Spring 1
10 Guide, Seal 1
11 Nut, Valve Lock 2
12 Nut, Valve Adjusting 2
13 Rocker, Valve 2
14 Rockshaft Bolt 2
15 Plate Subassembly, Lifter Stopper 1
16 Seat, Valve Spring 1
17 Cylinder Head Bolt 4
18 Stud Bolt 2
19 Head Subassembly, Cylinder 1
20 Stud Bolt 2
21 Gasket, Inlet 1
22 Plate, Carburetor Insulator 1
23 Carburetor Seal Gasket 1
24 Carburetor Assy. 1
25 Air Cleaner Seal Gasket 2
26 Wire Clip 2
27 Air Cleaner 1
28 Nut With Flange 2
29 Plug, Spark 1
30 Gasket, Cylinder Head 1
31 Position Pin - Type A 2
32 Valves Set 1
33 Ring Assy, Piston 1
34 Clip, Piston Pin 2
35 Piston 1
36 Pin, Piston 1
37 Rod, Connecting 1
38 Lifter Subassembly, Valve 2
39 Tappet, Valve 2
40 Shroud, Cylinder Body 1
41 Bolt 1
42 Bolt, Drain Plug 2
43 Flat Washer 2
44 Crankcase Subassembly. 1
45 Seal, Oil 1
46 Plug, Rubber 1
47 Protector, Oil 1
48 Wire Clip 1
49 Hex Socket Flange Face
Bolt - Small Series
1
50 Motor, Starting 1
51 Hex Socket Flange Face
Bolt - Small Series
2
52 Wire Clip 1
53 Coil Subassembly, Charge 1
54 Hex Socket Flange Face
Bolt - Small Series
2
55 Coil, Ignition 1
56 Bolt 2
Part Description Qty
57 Clamp, Charge Coil 1
58 Hex Socket Flange Face
Bolt - Small Series
1
59 Flywheel Subassembly 1
60 Impeller 1
61 Pulley,Starter 1
62 Nut, Flywheel 1
63 Shroud 1
64 Bolt 5
65 Starter Assy, Recoil 1
66 Bolt 3
67 Hex Socket Flange Face
Bolt - Small Series
2
68 Hex Socket Flange Face
Bolt - Small Series
2
69 Cushion, Muffler Insulator Rubber 1
70 Cover, Muffler Inner 1
71 Hex Socket Flange Face Bolt
- Large Series - Grade B
7
72 Cover, Muffler Side 1
73 Muffler Assy. 1
74 Gasket, Exhaust Outlet 1
75 Hex Socket Flange Face
Bolt - Small Series
2
76 Pipe, Exhaust 1
77 Type 1 Nut 2
78 Gasket, Exhaust Outlet 1
79 Muffler Outer Cover 1
80 Bracket,Muffler 1
81 Camshaft Assy. 1
82 Crankshaft Assy. 1
83 Deep Groove Ball Bearing 1
84 Shaft Assy, Balancing 1
85 Hex Socket Flange Face
Bolt - Small Series
2
86 Sensor, Engine Oil 1
87 Bolt 2
88 Control Assy, Throttle 1
89 Spring, Governor 1
90 Cotter Pin 1
91 Nut With Flange 1
92 Bolt, Governor Support 1
93 Governor Bracket Subassembly 1
94 Rod, Governeor 1
95 Spring, Throttle Valve Returning 1
96 Seal, Oil 1
97 Nut With Flange 1
98 Flat Washer 1
99 Arm, Governor 1
100 Position Pin 2
101 Gasket, Crankcase 1
102 Gear Assy, Governor 1
103 Deep Groove Ball Bearing 1
104 Deep Groove Ball Bearing 1
105 Dipstick Subassembly, Oil 1
106 Cover, Crankcase 1
107 Bolt 7
108 Seal, Oil 1
109 Nut, Stator 2
110 Standard Spring Washer 2
