Page 16 For technical questions, please call 1-888-866-5797. ITEM 60622
SAFETY SETUP OPERATION MAINTENANCE
Parts Lists and Diagrams
Engine Parts List
Part Description Qty
1 Set Screw (M5 x 12) 1
2 Gasket 1
3 Reel 1
4 Starter Rope 1
5 Spiral Spring 1
6 Rewind Starter Assy. 1
7 Starter Handle 1
8 Handle Clip 1
9 Screw (M5 x 20) 6
10 Crankcase Gasket 1
11 Nut (M8) 1
12 Startup Claw 1
13 Startup Reed 1
14 Cover 1
15 Outer Snap Ring (4) 1
16 Small Oil Seal 2
17 Crankcase Cover 1
18 Ball Bearing (6201/P5) 2
19 Crankshaft (Complete) 1
20 Woodruff Key (3 x 5 x 13) 1
21 Set Pin (B4 x 10) 2
22 Screw (M5 x 12) 2
23 Crankcase 1
24 Flow Guard 1
25 Set Pin (B4 x 10) 2
26 Support 1
27 Screw (M5 x 30) 4
28 Rotor 1
29 Nut (M8) 1
30 Stator 1
31 Flameout Line 1
32 Screw 1
33 Washer (B) 2
34 Return Spring 1
35 Cushion 2
36 Washer 2
37 Screw 2
38 Fan Shroud 1
39 Screw (M5 x 21) 4
40 Wire Clip 1
41 Piston Pin 1
42 Piston Pin Circlip 2
43 Piston 1
44 Piston Pin 1
45 Crankcase Gasket 1
46 Piston Ring 2
47 Cylinder Gasket 1
Part Description Qty
48 Cylinder 1
49 Bolt (M5 x 18) 4
50 Cylinder Cover 1
51 Spark Plug 1
52 Spark Plug Clip Reed 1
53 Spark Plug Cover 1
54 Spark Plug Cap 1
55 Cap Cover 1
56 Top Cover 1
57 Screw (M5 x 20) 1
58 Muffler Insulator 1
59 Muffler 1
60 Socket Head Bolt (M5 x 12) 1
61 Socket Head Bolt (M5 x 12) 1
63 Stud 2
64 Nut (M6) 2
65 Muffler Protection Cover 1
66 Intake Port Gasket 2
67 Intake Port 1
68 Carburetor Gasket 1
69 Carburetor Assy. 1
70 Choke Switch 1
71 Washer 1
72 Nut (M4) 1
73 Air Cleaner Case 1
74 Bolt (M5 x 50) 2
75 Recoil Starter 1
76 Choke 1
77 Self Tapping Bolt (ST4.2 x 12) 1
78 Air Filter 1
79 Air Filter Cover 1
81 Head Cover Bolt 1
82 Gasoline Tank Strut 1
83 Latex Cover 1
84 Fuel Filter 1
85 Fuel Line 1
86 Fuel Line Plug 1
87 Fuel Line 1
88 Bolt (M5 x 20) 2
89 Fuel Tank 1
90 Packing Ring 1
91 Intake Strut 1
92 Intake 1
93 Fuel Cap 1
94 Fuel Cap Set 1
95 Primer 1
