Page 2 For technical questions, please call 1-888-866-5797. ITEM 60622
SAFETY SETUP OPERATION MAINTENANCE
Table of Contents
Specifications ............................................. 2
Safety ......................................................... 3
Setup .......................................................... 6
Operation .................................................... 8
Maintenance .............................................. 12
Troubleshooting ......................................... 14
Parts Lists and Diagrams .......................... 16
Warranties ................................................. 22
Specifications
Maximum Drilling Depth 22″
Auger Diameter 4″
Overall Bit Length 30-1/2″ Long
Drive Shaft 7/8″ Diameter x 1-1/2″ Long
Accessories
Auger Bit, Spark Plug Wrench,
Screwdriver, 2 Hex Keys
Engine Type
52cc / Single Cylinder
2 stroke / Recoil Start
Bore x Stroke 44 x 34
Compression Ratio 8.2:1
Displacement 52cc
Rotation viewed from PTO
(power takeoff - the output shaft)
Clockwise
Fuel
Type
25:1 - 90+ octane unleaded stabilizer-
treated gasoline with 2 cycle oil mix
Capacity 0.26 Gallons
Recommended Gear Oil SAE 80-90 Weight Gear Oil
Spark
Plug
Compatible
Types
NGK BPM7A
Bosch WS7F
Champion CJ7Y
Torch L7T
(resistive plugs only)
Gap 0.028~0.031″
Drilling Speed 150 RPM
