Part Description Qty
1a Starting Flange 1
2a Oil Seal (20 x 52 x 7) 1
3a Washer 1
4a Washer 1
5a Fender Ring (47) 1
6a Bearing (6204) 1
7a Worm Gear 1
8a Gearbox 1
9a Hex Head Screw (M6 x 25) 4
10a Stud (M6) 4
11a Nut (M6) 4
12a Washer 1
13a Gear 1
14a Lining (not shown) 1
15a Transmission Socket 1
16a Washer 1
17a Gasket 1
18a Gearbox Cover 1
19a Oil Seal (20 x 35 x 7) 1
20a Oil Fill Plug 1
Part Description Qty
21a Gearbox Fill Level Plug (M6 x 12) 1
22a Washer 1
23a Paper Underlay 1
24a Screw (M6 x 16) 6
25a Cushion Frame 1
26a Liner Tube 5
27a Washer 10
28a Washer 6
29a Hex Head Screw (M6 x 30) 5
30a Screw 4
31a Nut 4
32a Washer 4
33a Bit 1
34a Pin 1
35a R-Pin 1
36a Fuel Mix Container 1
37a Hex Wrenches 2
38a Open End Wrench 1
39a Spark Plug Socket 1
40a Screwdriver 1
Parts List A - Auger
