Page 2 For technical questions, please call 1-888-866-5797. ITEM 62323
Table of Contents
Specifications ............................................. 2
Safety ......................................................... 3
Setup .......................................................... 6
Operation .................................................... 9
Maintenance .............................................. 14
Troubleshooting ......................................... 18
Parts Lists and Diagrams .......................... 22
Warranties ................................................. 26
Specifications
Chipper/Shredder Specifications
Chipper Chute Capacity 3" Maximum Limb Diameter
Chipper Dimensions 3-1/8" x 5" opening
Hopper Capacity 1/2" Maximum Limb Diameter
Hopper Dimensions 17-1/2" L x 15" W
Ground Clearance 3-1/2″ At Lowest Point
Wheels 12" Diameter x 3-1/4" W
Engine Specifications
Displacement 212cc
Engine Type
Horizontal Single Cylinder
4-stroke
Cooling System Forced air cooled
Fuel
Type
87+ octane stabilizer-treated
unleaded gasoline
Capacity 0.9 Gallon
Engine Oil
Type SAE
10W-30 above 32° F
5W30 at 32° F or below
Capacity 20 ounces (0.6 Liter)
Run Time @ 50% Load
with full tank
3 hr.
Sound Level at 22 feet 104 dB
Bore x Stroke 70 mm x 55 mm
Compression Ratio 8.5:1
Rotation viewed from PTO
(power takeoff - the output shaft)
Counterclockwise
Spark Plug
Type
NGK
®
BP-6ES
NHSP
®
/ Torch
®
F6TC
Gap 0.7 - 0.8 mm
Valve Clearance
Intake 0.10 - 0.15 mm
Exhaust 0.15 - 0.20 mm
Speed Idle 1740 ± 50 RPM
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency. For warranty information, refer to the last pages of this manual.
