Parts Lists and Diagrams
Parts List
Part Description Qty.
1 Flange Bolt M8 x 16 4
2 Batten 1
3 Hopper Flap 1
4 Hopper 1
5 Nylon Lock Nut M6 19
6 Bolt M6 x 16 15
7 Handle 1
8 Bolt M8 x 82 4
9 Flange Nut M8 1
10 Bolt M6 x 12 3
11 Lock Washer Ø6 5
12 Flat Washer Ø6 11
13 Access Panel 1
14 Rotor Housing 1
15 Flat Washer Ø8 3
16 Axle Assembly 1
17 Wheel 2
18 Cotter Pin Ø3 x 30 2
19 Flat Washer Ø16 2
20 Bolt M8 x 20 10
21 Socket Head Cap Screw M8 x 100 1
22 Discharge Port Cover 1
23 Main Housing 1
24 Socket Head Cap Screw M8 x 130 1
25 Washer Ø12 1
26 Lock Washer Ø8 22
27 Socket Head Cap Screw M8 x 50 4
28 Flat Washer Ø8 32
29 Long Spacer Bushing 4
Part Description Qty.
30 L-Hammer 2
31 Socket Head Cap Screw M8 x 20 2
32 Washer 4
33 Rectangular Hammer 2
34 Nylon Lock Nut M8 31
35 Socket Head Cap Screw M8 x 25 4
36 Chipper Blade 2
37 Rotor Assembly 1
38 Engine Plate 1
39 Chipper Chute 1
40 Chipper Chute Flap 1
41 Chipper Chute Mounting Ring 1
42 Engine Mounting Block 1
43 Engine Flat Key 1
44 Engine 1
45 Bolt M8 x 65 4
46 Support Leg 1
47 Left Brake Lever 1
48 Left Brake Pad 1
49 Right Brake Pad 1
50 Right Brake Lever 1
51 Socket Head Cap Screw M6 x 16 2
52 Socket Head Cap Screw M6 x 25 2
53 Shock Absorber 4
54 Flat Washer Ø8 4
55 Bolt M8 x 16 3
56 Discharge Bag 1
57 Hopper Gasket 1
