Page 24 For technical questions, please call 1-888-866-5797. ITEM 62323
SAFETY SETUP OPERATION MAINTENANCE
Engine Parts List
Part Description Qty.
1A Cylinder Head Subassembly 1
2A Cylinder Head Gasket 1
3A Cylinder Head Cover Subassembly 1
4A Cylinder Head Cover Gasket 1
5A Breather Tube 1
6A Bolt 4
7A Stud 1
8A Stud 2
9A Pin 2
10A Cylinder Head Bolt 4
11A Spark Plug 1
12A Crankcase Subassembly. 1
13A Engine Oil Sensor 1
14A Governor Gear Assembly 1
15A Governor Arm 1
16A Drain Plug Bolt 2
17A Washer 2
18A Bearing 1
19A Seal, Oil 1
20A Governor Gear Washer 3
21A Pin 1
22A Bolt 2
23A Crankcase Cover Assembly 1
24A Bearing 1
25A Oil Seal 1
26A Crankcase Gasket 1
27A Pin 2
28A Oil Dipstick Subassembly 1
29A Engine Oil Plug Subassembly 1
30A Bolt 6
31A Crankshaft Assembly 1
32A Piston Pin Clip 2
33A Piston 1
34A Piston Pin 1
35A Connecting Rod 1
36A Piston Ring Assembly 1
37A Air Cleaner Element Subassembly 1
38A Rubber Jacket 1
39A Camshaft Assembly 1
40A Valve 1
41A Stud 1
42A Valve Spring Seat 2
43A Valve Lock Clamp 4
44A Nut 1
45A Seal Guide 1
46A Valve Tappet 2
47A Valve Lifter 2
48A Lifter Stop Plate Subassembly 1
49A Valve Adjusting Bolt 2
50A Valve Rocker Arm 2
Part Description Qty.
51A Valve Adjusting Nut 2
52A Valve Lock Nut 2
53A Valve Spring 2
54A Bolt 3
55A Recoil Starter Assembly 1
56A Shroud 1
57A Cylinder Body Shroud 1
58A Lower Shield 1
59A Oil Protector 1
60A Stop Engine Switch Subassembly 1
61A Bolt 4
62A Bolt 2
63A Bolt 1
64A Collar 1
65A Bolt 1
66A Carburetor Assembly 1
67A Air Cleaner Gasket 1
68A Carburetor Gasket 1
69A Carburetor Insulator Plate 1
70A Carburetor Insulator Gasket 1
71A Nut M6 2
72A Air Cleaner 1
73A Exhaust Outlet Gasket 1
74A Nut M8 2
75A Muffler Assembly 1
76A Fuel Tank 1
77A Fuel Strainer 1
78A Fuel Tank Cover 1
79A Fuel Tank Oil Outlet Subassembly 1
80A Collar 2
81A Fuel Tube 1
82A Bolt 1
83A Nut M6 2
84A Flywheel Nut 1
85A Starter Pulley 1
86A Impeller 1
87A Flywheel Subassembly 1
88A Bolt 2
89A Ignition Coil 1
90A Throttle Control Assembly 1
91A Governor Spring 1
92A Governer Rod 1
93A Throttle Valve Return Spring 1
94A Governor Support Subassembly 1
95A Bolt 2
96A Governor Support Bolt 1
97A Nut 1
98A One Way Valve 1
99A Clamp 1
100A Fuel Steam Rubber Hose 1
When ordering replacement parts from this list, the “A” suffix must be included in order to get the correct part.
