Page 20 F*+&<(=:$#='B&T;("<#*$"E&@B('"(&='BB&NOPPPOPRROUVSV8 ITEM 63404
7-F652 3[6D-503. 4-0.56.-.,6765![
['+<"&1#"<"&'$)&H#'%+'?"
['+<"&1#"<
['+< H("=+#@<#*$ h<A
1 Head Subassembly, Cylinder 1
2 Gasket, Cylinder Head 1
3 Cover Subassembly, Cylinder Head 1
4 Gasket, Cylinder Head Cover 1
5 Tube, Breather 1
6 Bolt 4
7 Stud 2
8 Stud 2
9 Pin 2
10 Bolt, Cylinder Head 4
11 Plug, Spark 1
12 Block,High Tension Line 1
13 Seal, Oil 1
14 Bolt, Drain Plug 1
15 Flat Washer 1
16 Crankcase Subassembly. 1
17 Bearing 1
18 Gear Assy, Governor 1
19 Arm, Governor 1
20 Circlip 1
21 Pin 1
22 Seal, Oil 1
23 Cover, Crankcase 1
24 Bearing 1
25 Gasket, Crankcase 1
26 Pin 2
27 Dipstick Subassembly, Oil 1
28 Bolt 6
29 Crankshaft Assy. 1
30 Ring Set, Oil 1
31 Clip, Piston Pin 2
32 Piston 1
33 Pin, Piston 1
34 Rod, Connecting 1
35 Ring (1) 1
36 Ring (2) 1
37 Camshaft Assy. 1
38 Valve, Exhaust 1
39 Valve, Intake 1
40 Seat, Valve Spring 2
41 Spring, Valve 2
42 Tappet, Valve 2
43 Lifter Subassembly, Valve 2
44 Plate Subassembly, Lifter Stopper 1
45 Bolt, Valve Adjusting 2
46 Rocker, Valve 2
47 Valve Adjusting Nut 2
48 Nut, Valve Lock 2
49 Starter Assy, Recoil 1
50 Bolt 3
51 Shroud 1
52 Bolt 4
53 Deflector, Crankcase Air 1
54 Bolt 1
55 Shroud, Cylinder Body 1
56 Bolt 1
57 Shroud Shield 1
58 Plug, End 1
59 Gasket, Carburetor 2
60 Plate, Carburetor Insulator 1
61 Gasket, Air Cleaner 1
62 Carburetor Assy. 1
['+< H("=+#@<#*$ h<A
63 Cleaner, Air 1
64 Nut 2
65 Muffler Assy. 1
66 Gasket, Exhaust Outlet 1
67 Nut 2
68 Tank, Fuel 1
69 Fuel Strainer 1
70 Cover, Fuel Tank 1
71 Bolt 3
72 Outlet Subassembly, Fuel Tank Oil 1
73 Tube, Fuel 1
74 Collar 2
75 Clip 1
76 Nut, Flywheel 1
77 Pulley,Starter 1
78 Impeller 1
79 Flywheel Subassembly 1
80 Bolt 2
81 Coil, Ignition 1
82 Nut 1
83 Support Subassembly, Governor 1
84 Rod, Governor 1
85 Spring, Throttle Valve Returning 1
86 Spring, Governor 1
87 Bolt 2
88 Control Assy, Throttle 1
89 Hoop Subassembly, Hose 3
90 Inlet Screen 1
91 Screen Connector 1
92 Bolt 7
93 Washer 7
94 Bolt 2
95 Bolt 2
96 Washer 4
97 Inlet Water Gasket 1
98 Inlet, Water 1
99 Plug, Thread 2
100 Washer, Screw Plug 2
101 Water Outlet 1
102 Outlet Gasket 1
103 Pump Body 1
104 Whorl Case Sealing Ring 1
105 Case, Whorl 1
106 Impeller, Water Pump 1
107 Cushion, Water Pump Joint 1
108 Ring, Impeller Seal 1
109 Seal, Porcelain 1
110 Seal Assy, Mechanism 1
111 Bolt 4
112 Gasket 4
113 Joint, Water Pump 1
114 Pump Assy, Water 1
115 Frame Assy, Engine 1
116 Bottom Plate 1
117 Tube, Handle 1
118 Bolt 2
119 Bolt 4
120 Bolt 4
121 Nut 4
122 Nut 4
123 Seat, Engine Frame Shock Absorption 4
124 Bolt 4
