Page 3
For technical questions, please call 1-888-866-5797.
70476
Table of Contents
Specifications ............................................................... 3
Safety ...........................................................................4
Setup ...........................................................................12
Operation .....................................................................18
Maintenance ................................................................ 28
Troubleshooting ........................................................... 33
Parts List and Diagram ................................................ 37
Warranties ...................................................................40
Specifications
Generator
AC Output
(Gasoline)
120 / 240 VAC, 60 Hz, 83.3 / 41.7 A, 1 Phase
10000 Running Watts
13000 Maximum Starting Watts
AC Output
(LPG / Propane)
120 / 240 VAC, 60 Hz, 75.8 / 37.9 A, 1 Phase
9100 Running Watts
12000 Maximum Starting Watts
AC Output
(Natural Gas)
120 / 240 VAC, 60 Hz, 65.0 / 32.5 A, 1 Phase
7800 Running Watts
10000 Maximum Starting Watts
Receptacles
4 x 120 VAC, 20 A GFCI
1 x 120 VAC, 30 A Twist Lock L5-30R
1 x 120 / 240 VAC, 30 A Twist Lock L14-30R
1 x 120 / 240 VAC, 50 A NEMA 14-50R
Displacement 458 cc
Compression Ratio 8.8:1
Engine Type Horizontal Single Cylinder, 4-stroke, OHV
Cooling System Forced air cooled
Fuel
Type
87+ octane, stabilizer-treated unleaded
gasoline; LPG / Propane; or Natural Gas
Gasoline Tank 10.7 Gallon / 40.5 Liter
LPG / Propane Tank 40 lb tank minimum
Natural Gas
Fuel Rating: 1000 BTU /cu ft
Minimum Fuel Supply Size: 1/2"
Supply Pressure: 5~9 WC (1.2-2.24 KPa)
Maximum Flow Rate: 125000 BTU / hr
Engine Oil
Type SAE 10W-30
Capacity 1.3 Quart / 1.2 Liter
Run Time @ 50% Load with full gasoline tank 12.1 hours
Run Time @ 50% Load with 100 lb LPG tank 16 hours
Sound Level at 23 feet, 50% load 78.5 dB (A)
Bore x Stroke 90 mm x 72 mm
Spark Plug
Type LG / Torch F7RTJC or equivalent
Gap 0.031"– 0.039"
Valve
Clearance
Intake 0.002"– 0.004"
Exhaust 0.002"– 0.004"
Engine Speed 3600 RPM
Electric Start Battery 12 V – 14 Ah Lead-Acid Non-Spillable
Remote Control Battery 3V CR2032
Internal Battery
3V CR2450
Contains non-replaceable batteries
Battery
Charger
Input: 100 –240 VAC, 50 / 60 Hz, 0.5 A Max
•
Output: 14 VDC, 0.8 A
Cable Length: 5.9 feet
The emissions control system for this Engine is warranted for standards set by the
U.S. Environmental Protection Agency. For warranty information, refer to the last pages of this manual.
In reference to the remote: Changes or modifications not expressly approved by Harbor Freight Tools
could void the user’s authority to operate the equipment. FCC ID: 2BBOR-QJ003
